High Flow Hydraulic Grouting Pumping Stations

Gaodetec high flow hydraulic grouting pumping stations are widely used for grouting. Due to the high pressure, high flow, high flow hydraulic grouting pumping station is used for ground treatment and stabilization of railway, highway, bridge, dam, industrial and civil construction, geological disaster control and other projects.

 The high flow hydraulic grouting pump station uses a high shear high speed grouting mixer with a volume of 350L, agitator volume of 800L, grouting pressure of 0 70Bar, and grouting flow of 0 70L / min. Mixer A scroll mixer can ensure The pulp is evenly and quickly mixed.

The high flow hydraulic grouting pumping station has the following functions:

1. Pump pressure is 0 70 Bar. The output of the pump is 0 70L / min. Both can be adjusted stepless

2. A double cylinder single acting grouting pump ensures continuous grouting without kicking.

3. Quickly and easily clean the valve cavity

4. The outlet of the grout pump is equipped with a buffer. This can further reduce grout pressure fluctuations

5. Includes special tools to ensure quick piston replacement and reduce replacement time

6. Fewer spare parts ensure lower maintenance costs

7. The mixer and agitator are switched by the squeeze handle, which is safe, reliable and easy to operate

The high flow hydraulic grouting pumping station can stir, pump, and grout most of the premixed cement construction materials, making it suitable for a variety of applications. Such as cement, bentonite solid grouting and silica sand. The special mixing effect of cement or bentonite with water is produced in the mixer due to the high turbulence generated in the pump casing. This turbulent flow with high shear forces separates the cement or bentonite particles, forming a fully hydrated suspension. Cement is the oldest and most widely used grouting material in grouting projects.

If your project requires a suitable high flow hydraulic grouting pumping station, please help us confirm the following:

1. What pressure do you need?

2. What process do you need?

3. Do you want a grout pump with an electric motor, a diesel engine or an air motor?

If you want to use a motor to fill the pot of the grout pump, also check the voltage on site.

If you don't  know the information, don't worry. Gaodetec also has its own technical team and R & D capabilities. Please send your project requirements for high flow hydraulic grouting pumping stations. We will recommend the appropriate model or according to your needs Design a suitable large flow hydraulic grouting pumping station
